JGD flexible rubber joint
The jgd flexible rubber joint produced by Zhongyuan Innovation Pipeline Equipment Co., Ltd. in Gongyi City is a new type of rubber inner membrane process made by our technicians after long-term research and production. It is formed by continuous high temperature vulcanization.
"It is no accident to meet you". Thank you very much for clicking on the "ZhongYuan " website in the vast information on the Internet. It would be a great honor for ZhongYuan to provide you with [JGD flexible rubber joint] technical services! Next you will see the JGD flexible rubber joint technical information prepared by ZhongYuan JGD flexible rubber joint technology for you. I hope it will be helpful to your choice!
JGD flexible rubber joint peculiarity：
1, flexible rubber joint small size, light weight, good flexibility, easy installation and maintenance.
2, flexible rubber joint installation can produce transverse, axial, angular displacement, not by the pipe through the heart, flange unparallel restrictions.
3, flexible rubber joint working can reduce the structure transmission noise, strong vibration absorption ability.
4, The flexible rubber joint independently developed by our company can more effectively prevent the erosion of corrosive media on the inner wall of the rubber joint in the pipeline with high temperature resistance, acid and alkali resistance and oil resistance, and improve the service life.
JGD flexible rubber joint application field：
Due to its high cost performance and superior performance in the working process, it can be widely used in chemical industry, construction, water supply, drainage, petroleum, light and heavy industry, refrigeration, health, water heating, fire protection, power and other basic projects.
JGD flexible rubber joint price：
If you need the JGD flexible rubber joint produced by our factory and want to consult its price, please call to consult us, you can also contact our enterprise QQ, we have a special online customer service for you to answer in detail!
|
Nominal diameter
DN（mm） |
|
|
Length
L (mm) |
Axial compression
|
Axial stretching
|
Haorizontal isplacement
|
Angular deflection
|
|
32
|
95
|
8
|
4
|
8
|
15°
|
|
40
|
95
|
8
|
5
|
8
|
15°
|
|
50
|
105
|
8
|
5
|
8
|
15°
|
|
65
|
115
|
12
|
6
|
10
|
15°
|
|
80
|
135
|
12
|
6
|
10
|
15°
|
|
100
|
150
|
18
|
10
|
12
|
15°
|
|
125
|
165
|
18
|
10
|
12
|
15°
|
|
150
|
180
|
18
|
10
|
12
|
15°
|
|
200
|
210
|
25
|
14
|
15
|
15°
|
|
250
|
230
|
25
|
14
|
15
|
15°
|
|
300
|
245
|
25
|
14
|
15
|
15°
|
|
350
|
255
|
25
|
15
|
15
|
15°
|
|
400
|
255
|
25
|
15
|
15
|
12°
|
|
450
|
255
|
25
|
15
|
22
|
12°
|
|
500
|
255
|
25
|
16
|
22
|
12°
|
|
600
|
260
|
25
|
16
|
22
|
12°
|
|
700
|
260
|
25
|
16
|
22
|
12°
|
|
800
|
260
|
25
|
16
|
22
|
12°
|
|
900
|
260
|
25
|
16
|
22
|
10°
|
|
1000
|
260
|
25
|
16
|
22
|
10°
|
|
1200
|
260
|
26
|
18
|
24
|
10°
|
|
1400
|
450
|
28
|
20
|
26
|
10°
|
|
1600
|
500
|
35
|
25
|
30
|
10°
|
|
1800
|
500
|
35
|
25
|
30
|
10°
|
|
2000
|
550
|
35
|
25
|
30
|
10°
|
Instructions:
1. Flexible rubber joints can greatly reduce the vibration and noise of the pipeline system, and can fundamentally solve the problems of interface displacement, axial expansion and different concentricity of various pipelines.
2. According to different materials, it can be made into acid-resistant flexible rubber joints, alkali-resistant flexible rubber joints, corrosion-resistant flexible rubber joints, oil-resistant flexible rubber joints, heat-resistant flexible rubber joints and other varieties, flexible rubber joints to adapt to a variety of media and environment.
3. The material is very rubber, flexible rubber joint good sealing, light weight, easy installation and maintenance, long service life, flexible rubber joint to avoid contact with sharp metal instruments, so as not to puncture the ball.
4. Flexible rubber joints can be used in the overhead elastic bracket, and the bolts should be tightened diagonally during installation.
5. If the pipe pressure is too high, use limited bolts to connect the two flanges together.
6. Flexible rubber joint flange connection standard adopts GB4216.3-4216.5 standard, such as other standards, can be explained separately. The working pressure grade of flexible rubber joint is 0.6MPa, 1.0MPa, 1.6MPa, 2.5MPa.
